C7H170-M – Supermicro C7H170-M Socket LGA1151 Intel H170 Express Chipset Micro-ATX System Board (Motherboard) Supports Core i3/i5/i7 Series DDR4 4x DIMM
Description
Supermicro C7H170-M C7H170-M Socket LGA1151 Intel H170 Express Chipset Micro-ATX System Board (Motherboard)
Technical Information
| Ethernet Standard | Gigabit Ethernet |
|---|---|
| Memory Technology | DDR4 SDRAM |
| RAM Genre | UDIMM |
| Socket Type | Socket H4 LGA-1151 |
| Chipset Vendor | Intel |
| Chipset Model | H170 |
| Quantity of Processor Supported | 1 |
| Supported Processor | Core i7 |
| Built-in Processor Vendor | Intel |
| Built-in Processor Type | Core i7 |
| Built-in Processor Model | i7-6700 |
| Built-in Processor Speed | 3.4 |
| Built-in Processor Core | Quad-core (4 Core) |
| Quantity of Memory Slots | 4 |
| Maximum Memory | 64 |
| Controller Type | Serial ATA/600 |
| Raid Supported | Yes |
| Raid Levels | 0, 1, 5, 10 |
| Onboard Video | CPU Dependent Video |
| Graphics Controller Vendor | Intel |
| Graphics Controller Model | Intel HD Graphics |
| Audio Channels | 7.1 |
Interfaces/Ports
| Quantity of Expansion Slots | 3 |
|---|---|
| Quantity of PCI Express Slots | 3 |
| Quantity of PCI Express x1 Slots | 1 |
| Quantity of PCI Express x4 Slots | 1 |
| Quantity of PCI Express x16 Slots | 1 |
| Quantity of USB Ports | 10 |
| Quantity of USB 2.0 Ports | 4 |
| S/PDIF Port | Yes |
| HDMI Port | Yes |
| Display Port | Yes |
| DVI Port | Yes |
| Ethernet Port (RJ-45) | Yes |
| Quantity of Ethernet LAN Ports (RJ-45/SFP/SFP+) | 1 |
| Quantity of SATA Interfaces | 4 |
| Quantity of M.2 Interfaces | 1 |
| Quantity of Onboard USB Ports | 10 |
| Quantity of Onboard USB 3.0 Ports | 6 |
| Onboard S/PDIF Header | Yes |
Physical Characteristics
| Form Factor | Micro ATX |
|---|---|
| Height | 9.6 |
| Width | 9.6 |
Miscellaneous
| Compliance Standards | RoHS |
|---|
Compatibility
- SC743TQ-865B-SQ
- SC732G-903B
- SC732D2-500B
- SCGS50-000R
Additional information
| Height |
9.6 |
|---|---|
| Width |
9.6 |
| Compliance Standards |
RoHS |
| Ethernet Standard |
Gigabit Ethernet |
| Form Factor |
Micro ATX |
| Memory Technology |
DDR4 SDRAM |
| Ram Genre |
UDIMM |
| Socket Type |
Socket H4 LGA-1151 |
| LAN Ports RJ45/SFP/SFP+ |
1 |
| HDMI Port |
Yes |
| Quantity of Expansion Slots |
3 |
| Chipset Vendor |
Intel |
| Display Port |
Yes |
| DVI Port |
Yes |
| Quantity of USB Ports |
10 |
| Chipset Model |
H170 |
| Processors Supported |
1 |
| Supported Processor |
Core i7 |
| Built-in Processor Vendor |
Intel |
| Built-in Processor Type |
Core i7 |
| Built-in Processor Model |
i7-6700 |
| Built-in Processor Speed |
3.4 |
| Built-in Processor Core |
Quad-core (4 Core) |
| Quantity of Memory Slots |
4 |
| Maximum Memory |
64 |
